Flex Faraday Xtreme™
Individually Shielded Signals (Patented)
Request More Information
Enhanced Technology Engineered With Precision
Nortech’s FFX™ offers unparalleled control over crosstalk and impedance, dramatically reducing electromagnetic interference. Our Flex Faraday technology enhances parallel transmission alignment and maximizes data density, setting a new standard for performance and reliability. Experience the future of signal transmission with our EMI shielded flexible circuit, Flex Faraday Xtreme™.
Flex Faraday Xtreme™
Individually Shielded Flex Circuit Traces
Flexible Printed circuitry for transmitting high frequency signals
- Phase-matched individually shielded circuits
- Controlled isolation and crosstalk
- Delivers parallel transmission at tuned frequencies
- Precision attenuation and impedance
- Minimizes Electromagnetic Interference at the trace level
- Stripline waveguide design approach
- Customizable layouts available
- Circuits can be optimized for signal performance
- Rigid-flex PCBA options allow advanced design options
- Custom headers or wired U.FL connectors
Replace Micro-Coaxial Cables With a Tuned and Miniaturized EMI Shielded Flexible Circuit
Tuned EMI Shielded Flexible Circuit
Nortech is at the forefront of flexible circuitry technology particularly suited for demanding applications. Cutting-edge systems such as medical devices, military equipment, antennas and ultra-light products require highly reliable waveguide performance. FFX™ marks a significant advancement over conventional micro-coaxial implementations.
FFX™ combines control signals and high-speed data channels in a dense, lightweight and flexible package.
Examples of applications benefiting from FFX™:
- Parallel data transmission
- Micro-coaxial alternative
- PCBA board to board
- Antenna array systems
- Imaging technologies
- Communications
- Robotics
- Avionics
Our customizable EMI shielded flexible circuit technology excels in achieving your application’s size, weight and environmental challenges. FFX™ significantly reduces cross talk and boosts performance through superior intra-lane skew control. With steadfast dedication to innovation, Nortech stands as your premier partner for challenging data transmission solutions.
